Vertical machine center XH7125
Request a Quote
Out of Stock
Main features：
1. mini cnc milling economic machine center XH7125 is with box guideways, ensuring the machines machining accuracy and stability.
2.The small vmc machine can be with taiwan arm type tool magazine or drum type tool magazine with 10 tools capacity.
It can change tools quickly.
3.The machine is with RS232 interface, separated handwheel, spindle blowing chip removal system.
Nationwide
Delivery
Delivery
Pay via
M-Pesa
M-Pesa
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Countrywide dispatch with reliable courier partners across Kenya.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
Specifications
| Item | XH7125 |
| Working table size (mm) | 600×250 |
| T-slot No./Width/Distance (mm) | 3/14/75 |
| Max.load of worktable (kg) | 150 |
| X-axis travel (mm) | 400 |
| Y-axis travel (mm) | 240 |
| Z-axis travel (mm) | 400 |
| Distance from spindle nose to table surface (mm) | 60—460 |
| Distance from spindle axis to column guideway (mm) | 325 |
| Feed speed (mm/min) | 2.5--3000 |
| Spindle nose taper | BT30 |
| Spindle speed (rpm) | 60-8000 |
| Spindle power (kW) | 3.7 |
| Feed motor torque of X/Y/Z (Nm) | 2007/7/7 |
| Rapid feed speed X/Y (mm/min) | 8000 |
| Rapid feed speed Z (mm/min) | 6000 |
| Tool magazine capability (qty) | 10pcs |
| Tool magazine type | Drum-type |
| Max.dia.of Tool (mm) | Φ92 |
| Max.length of Tool (mm) | 150 |
| Max.weight of tool (Kg) | 5 |
| X/Y/Z positioning accuracy (mm) | ±0.015 |
| X/Y/Z repeat positioning accuracy (mm) | ±0.005 |
| Machine Net/Gross weight (Kg) | 1500/1650 |
| Overall dimension | 165*210*190cm |
| Packing size | 193*223*223cm |
