Gap bed lathe machine GH1440A
Request a Quote
Out of Stock
Main features:
1. Gear drive headstock for quick change of spindle speeds
2. Cast iron stand increasing rigidity and reducing vibration
3. Precision V-beds are hardened and ground, incorporating a rigid webbed casting
4. Low voltage work light
5. Foot operated spindle brake with safety cut out switch
6. Slide out front swarf tray for easy cleaning
7. Change gears for metric and imperial thread cutting
8. Oil sight glass for head stock and gearbox
9. Adjustable taper roller bearings support the spindle
10. Overload clutch mechanism on auto power feed
11. Micro-adjustable length-stop onbed-way for accurate repetitive operation
12. 3.2HP/415V motor 16-speed(50-2000rpm)
13. Inching button is incorporated on the control panel for convenient spindle speed selection
14. Enclosed quick action gearbox for thread cutting and auto feeding
15. Powered longitudinal and cross feeds
16. D1-4 camlock spindle for quick chuck changes and safe reverse-direction turning. ISO standard
17. Removable gap bed-way for larger diameter jobs
18. Dual calibrated dials (except for saddle hand-wheel)
19. Chuck & change gear guards are fitted with micro switches
20. Coolant system with flexible hose
21. Slide out swarf tray
Nationwide
Delivery
Delivery
Pay via
M-Pesa
M-Pesa
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Countrywide dispatch with reliable courier partners across Kenya.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
| Model | GH1440A | |||
| Max.Swing.over bed | mm | Φ356(14') | ||
| Max.Swing.over cross slide | mm | Φ220(8-5/8') | ||
| Max.Swing.over gap | mm | Φ506(20') | ||
| Bed width | mm | 206(8') | ||
| Max.Distance between centers | mm | 1000(40') | ||
| Taper of spindle bore | MT#5 | |||
| Diameter of spindle bore | mm | Φ38(1-1/2') | ||
| Steps of spindle speeds | 16steps | |||
| Range of spindle speeds | r/min | 45-1800rpm | ||
| Spindle nose | D-4 | |||
| Metric thread range | mm | 0.45-7.5(22kinds) | ||
| Inch screw thread range | TPI | 4-112(40kinds) | ||
| Range of longitudinal feeds | mm | 0.03-0.688(0.0011-0.0271'in/rev) | ||
| Range of cross feeds | mm | 0.015-0.220(0.0003-0.01'in/rev) | ||
| Diameter of leadscrew | mm | Φ22(7/8') | ||
| Pitch of leadscrew | mm | 4(8T.P.I) | ||
| Travel of tailstock quill | mm | 120(4-3/4') | ||
| Diameter of tailstock quill | mm | Φ45(1-25/32') | ||
| Taper of tailstock quill | MT#3 | |||
| Main motor power | Kw | 1.5/2.4 | ||
| Packing size of lathe(LxWxH) | mm | 1900 x760 x1460 | ||
| Net Weight/Gross Weight | Kg | 960/875 | ||
